Tait P25. Instant, reliable communications is just the beginning

Tait Tough | TP9400


The TP9400 P25 Phase 2 portable series gives you more efficient networks and more possibilities. With multiple operating modes, safety-enhancing features, and a rugged, robust design, the TP9400 is engineered to meet the demanding standards of the public safety industry.

Why choose TP9400?

Rugged, Tough Build

Rugged, Tough Build

The robust, Tait Tough design of the TP9400 series offers IP65 and IP68 sealing and shock absorbing impact-protected corners, exceeds relevant MIL-STD-810G standards, and features a water-shedding grille which aids voice clarity in wet environments.

Cost-Effective Flexibility

Cost-Effective Flexibility

With multiple operating modes including analog, analog simulcast IP, 12.5kHz P25 Phase 1 FDMA conventional/trunked, P25 Phase 2 TDMA trunked, and LSM (CQPSK) decode capability in a single device, you can transition to a more spectrally efficient solution in a time frame that suits you. The TP9400 series also operates in VHF and 700/800MHz frequency bands.

Improved User Safety

Improved User Safety

Safety is the top priority for Public Safety organizations around the world. Ensure the safety of your first responders with TP9400 capabilities such as clear voice, location services, Man Down & Lone Worker functionality, AES encryption capability, and radio inhibit and uninhibit to allow management of lost or stolen radios.

Increased User Efficiency

Increased User Efficiency

The TP9400 series offers features that help increase operational effectiveness, including voice and data, simulcast support and pre-set status messages.

True Interoperability for More Choices

True Interoperability for More Choices

Interoperability with adherence to the P25 standards gives your organization greater vendor choice and increased competition.

Simplified, Secure Management

Simplified, Secure Management

The TP9400 series supports security-focused fleet management with Over-the-air Rekeying (OTAR) and Tait Key Fill Device (KFD) capabilities.

Technical Specifications

Frequency Bands

VHF 136-174MHz, UHF 400-470MHz, UHF 450-520MHz, 700/800MHz from 757-870MHz

Output Power

VHF: 5W, 3W, 2W, 1W
UHF: 4W, 2.5W, 2W, 1W
700/800MHz: 3W,2.5W,2W,1W


1,000 channels/50 zones
(2,000 channels/100 zones optional enhancement with software license)

Tait Tough

EMilitary Standards for high humidity, sand & dust, vibration, shock, rain, solar radiation, and more. IP68 & IP65 water and dust resistant. Operating temperature of -22ºFto+140ºF(-30ºCto+60ºC)

Receiver Sensitivity

Sensitivity (analog), 12dBSINAD: 0.22μV(-120dBm) in VHF and UHF, 0.22μV(-121dBm) in 700/800MHz
Sensitivity (P25), 5%BER: 0.22μV(-120dBm) in VHF and UHF, 0.22μV(-121dBm) in 700/800MHz


Dimensions (DxWxH)
With Li-Ion standard battery: 1.61x 2.56 x 5.35in (41x 65x 136mm) - excluding knobs
With Li-Ion standard battery: 1.77x 2.56 x 5.35in (45x 65x 136mm) - excluding knobs

With Li-Ion standard battery: 11.46oz (325g) - no antenna
With Li-Ion standard battery: 13.12oz (372g) - no antenna

Choose Your TP9400

TP9400 Color Options

TP9400 Accessories

TSM4 Speaker Mic TSM4 Speaker Mic

Key Features

  • Rugged dust proof and water submersible (IP68)
  • Tait design water shed grille and microphone
  • Two glove friendly function buttons (programmable emergency button)
  • 3W speaker
TSM3e-440x270 TSM3e Speaker Mic

Key Features

  • Dust proof and water submersible (IP67 rated with connector jack sealed)
  • Tait design water shedding grille and microphone
  • Function button (programmable emergency button)
Aina PTT Voice Responder Aina PTT Voice Responder

Key Features

  • Covert mode option
  • IP67 dust and water resistant
  • Easy to use – simple Bluetooth pairing, two PTT buttons, 3.5mm standard audio jack
Genesis Genesis

Key Features

  • Fully sealed against water and dust penetration to IP68
  • Large snap-action PTT suitable for use with gloves
  • Emergency button with large notch for easier actuation
Heavy Duty Behind Head Heavy Duty Behind Head

Key Features

  • Designed for use with a helmet or hat
  • Discreet c-style headband for comfortable, stable fit
  • In-line PTT
Earphone In-Ear Earphone In-Ear

Key Features

  • 2.5mm plug compatible with Evolution and Storm models
  • Designed to fit either the left or right ear
  • Quick disconnect earphone adapter for easy acoustic tube replacement
Ear Hanger Ear Hanger

Key Features

  • Soft rubber ear loop with speaker
  • Rotational clip to fit either the left or the right ear
  • 2.5mm connector
